  Overhead Eot Cranes

EOT cranesm as they are popularly known as, are electric overhead traveling cranes. An overhead crane is commonly referred to as a bridge crane. These cranes are commonly found in industrial setups. These consist of parallel runways with a traveling bridge spanning the gap. The lifting component of the crane travels along the bridge.

At Bhagirath Heavy TransmissionIndia, we manufacture EOT overhead cranes which are fabricated using optimum quality raw materials. Also, components such as M.S. angles, M.S Sheets, I beam, brakes and motors are also manufactured with good quality materials. Our machines are designed to carry a load ranging up to a limit of 100 tons. These find extensive usage in foundry, engineering and also machinery shops. As per specifications from our clients, we provide customized order delivery.

EOT cranes are of two types :

  • Single girder E.O.T cranes
  • Double Girder E.O.T cranes.

We also provide a few unique features in our cranes. They are of high durability and performance. They are sturdy and easy to maintain. Our cranes are additionally corrosion resistant.

Maintenance
Our cranes are easy to maintain that are extended completely or partially along the girder. We use the finest quality raw material in manufacturing different components and the system. We tailor our cranes as per the client needs.
Some unique attributes of our E.O.T cranes are

  • Customized designs that can match up with the budget of our customers.
  • Economical designs thatare provided by manual long and cross travel facility. It also has a provision for using either electrical hoist or a motorized chain pulley block.
  • Low headroomthatis aimed at reducing the cost of shed or building.
  • These are ideal powerhouse cranes which are used for maintenance.
  • Prices are highly competitive

We are well-established manufacturers and exporters of both single and double girder cranes.

Double girders :
Double girders serve the purpose of lifting weights up to 10 tons and extend to a span of about 30 m. They consist of 2 torsion-free box girders. Theyare


 Some of the unique features of Overhead EOT Cranes include:
• High performance
• Durable
• Sturdy
• Easy maintenance
• Corrosion resistance



  • DESIGN
  • MOTORS
  • GEAR BOXES
  • BRAKES
  • LIMIT SWITCHES
  • PUSH BUTTON STATIONS
  • SOFT STARTS
Compact dimensions, low weight, easy to operate and easy to maintain.
Motors will be Crane duty motors, squirral cage induction motors for hoists and cranes also slipering induction motors will be provided for heavy duty cranes as per the applications.
Precision flat helical / spur gear units in light alloy housings with case-hardened gears, high-grade surface treatment and permanent oil /grease lubrication.
Single / Dual-disc Electro Magnetic DC Brakes featuring automatic braking on power failure.
To prevent over hoisting & over lowering of hook.
Extra light, handling, easy to operate, aluminum, fabricated from extruded section.
Electric / Electronic soft start modules electrically coupled to the long travel drives to achieve jerk free, cushioned & smooth starts.

  MAINTENANCE PLATFORM WITH HAND RAILING :


Easy, simple & safe maintenance of the Crane extended partially or totally along the girder. Our array of EOT Cranes is developed using finest quality  raw material such as Ms Sheets, MS angles, I  beam, motors,  brakes. These are ideal for power house cranes where these  cranes are used for  maintenance. Our high performance  gamut requires low maintenance and can be tailored as per  the demand of clients.


  Following are the unique attributes of EOT cranes:

  • Optimum design of the structure avoiding dead weight  and reducing the cost of the equipment.
  • Very much suitable for power house cranes where these cranes are used for maintenance.
  • Economical Design by providing manual long and cross travel facility with a provision for using either an electric hoist or a motorized chain pulley block
  • Low head room which in turn reduces the cost of the shed/building
  • Customized design to match the budget of the customer
  • Highly Competitive Prices

  Single Girder E.O.T. Crane

  Technical Parameter for Single Girder E.O.T. Cranes


S.W.L. (M.T.)

Span (mtrs.)’s’

Head Room (mm) ‘c’

Wheel Base (mm)

Hook Approach (mm) E/F

End Clearance (mm) A

Wheel Load Per Wheel (Approx)

1. 5 750 1800 700 250 0.9
10 850 2400 700 250 1.02
15 900 2800 700 250 1.27
2. 5 850 2000 700 270 1.6
10 950 2400 700 270 1.7
15 1050 2800 700 270 1.9
20 1200 3600 700 270 2.3
3. 5 850 1900 800 275 2.07
10 950 2400 800 275 2.2
15 1100 2800 800 275 2.6
20 1300 3600 800 275 3.2
5. 10 1000 2400 900 275 3.5
15 1250 2800 900 275 4
20 1350 3600 900 275 4.4
7.5 10 1100 2400 950 300 5.02
15 1300 2800 950 300 5.5
20 1500 3600 950 300 6.02
10 10 1200 2400 1000 300 6.5
15 1400 2800 1000 300 7.1
20 1550 3600 1000 300 7.6
20 10 1250 2500 1000 300 9.4
15 1550 3000 1000 300 10.15
20 1600 4000 1000 300 10.7



     Double Girder E.O.T. Crane


We are a well established manufacturer and exporter of EOT cranes with double girders, that find application for the purpose of lifting & transporting the loads over 10 T and for span of more than 30 m. Comprising of 2 torsion-free box girders, these EOT cranes such as double girder eot cranes, traveling eot cranes, material handling eot cranes etc., are compatible, when heavy loads and wide spans are required. These double girders EOT cranes are offered by us in the load capacities of up to 100 T and with spans up to 50 M.
Capacity : 0.5 Ton to 100 Ton
Span : 3 Mtrs. To 30 Mtrs.
Lift : 0.5 Mtrs. To 35 Mtrs.

Our array of EOT Cranes is developed using finest quality  raw material such as Ms Sheets, MS angles, I beam, motors,  brakes. These are ideal for power house cranes where these  cranes are used for maintenance. Our high performance  gamut requires low maintenance and can be tailored as per  the demand of clients.

Following are the unique attributes of EOT cranes:

  • Optimum design of the structure avoiding dead  weight  and reducing the cost of the equipment.
  • Very much suitable for power house cranes where these cranes are used for maintenance.
  • Economical Design by providing manual long and cross travel facility with a provision for using either an electric hoist or a motorized chain pulley block
  • Low head room which in turn reduces the cost of the shed/building
  • Customized design to match the budget of the customer
  • Highly Competitive Prices
Technical Parameter for Double girder E.O.T. Cranes

S.W.L. (M.T.)

Span (mtrs.) ‘s’

Head Room (mm) ‘c’

End Clearance (mm) ‘A’

Hook Approaches

Wheel Base (mm) ‘W’

Total Weight in tones (Approx.)

Wheel Load (Approx) (MT)

(mm) ‘E’

(mm) ‘F’

5 10 1700 260 950 850 3600 10 6.2
15 1700 260 950 850 3800 11 6.8
20 1800 260 950 850 4000 14 8
7.5 10 1800 260 1000 900 3600 12 8.5
15 1800 260 1000 900 3800 15 9.5
20 1900 260 1000 900 4000 17 10
10 10 1900 260 1100 1000 3600 14 10
15 1900 260 1100 1000 3800 15 11
20 2100 280 1100 1000 4000 20 12
15 15 2400 280 1100 1000 3800 22 16
20 2600 280 1100 1000 4200 25 17
20 15 2500 320 1200 1000 4000 24 19
20 2700 320 1200 1000 4200 28 20
25 15 2700 320 1250 1100 4200 25 22
20 3000 320 1250 1100 4400 30 23
30 15 2800 320 1300 1100 4400 30 26
20 3000 320 1300 1100 4600 36 28
40 15 3200 330 1400 1200 4600 35 32
20 3500 330 1400 1200 4800 40 34
50 15 4000 360 1500 1250 4800 42 37
20 4500 360 1500 1250 5000 48 39
60 15 4200 425 1700 1350 5800 62 50
20 4700 425 1700 1350 6000 72 52
